Biometric Attendance Access Control System Face Recognition
Temperature Measurement
Details of product:
1. Support passenger aircraft booking, WeChat official development of
visitors self-help booking, user face registration function.
2. Support remote management of equipment.
3. 4mm tempered glass protection screen.
4. Face Angle is 30 degrees left or right, 30 degrees up or down.
5. Full view, multi-function, easy to use.
6. Dynamic face detection and tracking algorithm based on video stream
is adopted.
7. Support face recognition door opening, visual intercom door
opening, APP door opening, card opening, password opening and other
functions.
8. Professional and humanized inner structure, wiring neatly.
| Product model | YD101FRT01 |
Camera | Resolution | 2MP pixel |
| Type | Binocular wide dynamic camera |
| Aperture | F1.8 |
| Focus Distance | 50-150cm |
| White Balance | Automatic |
| Fill Light | LED and infrared double fill lights |
| Screen | Size | 10.1inch IPS LCD display |
| Resolution | 1280*720 |
Processor | CPU | RK3288 quad-core |
| Local Store | EMMC 8G |
| Network Module | Support Ethernet, wireless (WIFI) |
| Audio | Support for 2.5W /4R speakers |
Interface
| USB Interfaces | One USB2.0 interface |
| Wired Network Interface | 1 RJ45 Ethernet seat |
| Interface Reserved | Pick the lock switch |
| Interface Reserved | IC card reader/ID card reader/QR code |
| Identify High | 1.2-2.2 meters |
Function | Face Library Support | Max. 20000 |
| 1:N Face Recognition | Support |
| 1:1 Face Ratio | Support |
| Stranger Detection | Support |
| Identification Distance Configuration | Support |
| Device Interface | Interfaces include device management, people/photo management, record query, etc |
| Deployment Way | Support public cloud deployment, LAN use |
| Body Temperature Detection | Support |
Infrared thermal imaging module camera | Temperature Detection Distance | 1M (best distance 0.5M) |
| Temperature Measurement Accuracy | ≤±0.3℃ (10℃-26℃) |
| Temperature Measurement Range | 32 ℃ ~ 45 ℃ |
| Face Angle | 30 degrees left or right, 30 degrees up or down |
| Normal Temperature Direct Release | Support |
| Excessive Temperature Alarm | Support (temperature alarm value can be set) |
Conventional parameters | Protection Grade | IP65, certain outdoor dustproof and waterproof function |
| Power Supply | DC12V (+ / - 10%) |
| Working Temperature | - 10 ℃ to 50 ℃ |
| Working Humidity, | -10 ~ 90% relative humidity, no condensation |
| Power Consumption | 40W (Max) |
| Installation | Secure with screws through supporting columns |
| Equipment Size | 392 * 180 * 32 mm |
| Weight | 2.7KGS |
Real-picture
Product's details
Application
FAQ
Q:Are you a factory or a trading company?
A:We are a OEM/ODM factory.
Q:What is the company's business philosophy?
A:Quality first, service first.
Q:How to ensure product quality?
A:Triple detection:
1) Raw material testing.
2) Detection after assembly is completed.
3) Detection after 48 hours of running.
Q:What is the minimum order quantity?
A:The MOQ is 1. Welcome to order samples. Quality is our
confidence.
Q:How to place bulk order?
A:1)Tell us model number,quantity,color and other special
requirements.
2)Proforma Invoice will be made and sent for your approval.
3)Production will be arranged upon receipt of your approval and
payment or deposit.
4)Goods will be delivered as stated on the proforma invoice.
Q:Do you have any After-Sales service?
A:Yes!Our products have professional After-sales Department.
If you have any technical problem or question with the
goods,welcome to contact us directly.
Q:What is your standard lead time for sample and bulk order?
A:Sample within 7-15 days,bulk order is depends on quantity.
