Indoor Touch Screen Advertising Displays Wall Mounting Vertical LCD
Advertising Display
Details of product :
1. Many specifications and models, size series, variety, convenient
and flexible use, maintenance, update, upgrade easy, long service
life.
2. Fast response time, fast and smooth use.
3. Standby all day long, no worry about Lifespan.
4. Low voltage applications, low drive voltage, solid use safety
and reliability improvement.
5. E-LED backlight, energy saving, high brightness, clear image.
6. Explosion-proof glass, protecting passerby and LCD panel.
7. Sensitive touch box, click < 8ms, continuous writing <
3ms.
8. Video format is supported PAL/NTSC.
| LCD |
| Brand | BOE |
| Panel Type | a-Si TFT open cell and LED backlight |
| Application | Indoor |
| Panel Size | 43" |
| Display Colors | 8- bit, 16.7M |
| Number of Pixels | 1920×1080P |
| Viewing Angle | 89°(U) / 89°(D) / 89°(L) / 89°(R) |
| Luminance of White | 380 cd/m² |
| Working Life | More than 6000hrs |
| Touch Screen |
| Technology | Infrared System ( IR touch) |
| Touch Points | 10 point |
| Accuracy | Less than 2.5mm |
| Resolution | 25ppi(Min.) |
| Cover Glass | 4～6mm,hardness more than 7 mohs |
| Android OS |
| OS | Android OS |
| CPU | RK3288 |
| RAM | 2GB |
| Storage | 8GB |
| TF card slot | Support MAX 32G |
| Video Output | HDMI Video Output |
| Audio Output | Dual-channel stereo audio output |
| Network | LAN(RJ45) |
| External Interfaces | USB 2.0 × 2,RJ45(LAN) × 1 |
| Internal Interfaces | Earphone Output × 1,USB 3.0 Type-A × 1,Micro SD × 1,USB Type-C OTG×
1 |
| RTC | Support |
| Language | English (United States Default, Multi-language supported) |
| External Camera Module |
| Dynamic Resolution | 1920×1080 |
| Image Pixel | 200W |
| Integration Microphone | Support |
| Focus Mode | Manual focusing |
| Mounting | Side direction with machine |
The Real-picture of the Wall Mounted Digital Dispaly
The Product's details of the Wall Mounted Digital Dispaly
The Application of the Wall Mounted Digital Dispaly
FAQ
Q:Are you a manufacturer or Trading company?
A:We are manufacturer which offer OEM/ODM service.
Q:What brand of screen is used?
A:All our screen adopt A+ BOE panel , Durable Aluminum Frame Design with Tempered Glass Surface.
Q:What are your advantages?
A:We have our own ERP systems : Shorten lead times at low cost with
responsive production planning.
Q:Can I customize the product I ordered?
A:Absolutely yes, customization offer from customers are most
welcome in our company.
Q:How does your manufacturer do regarding quantity control?
A:Quantity is priority. Our manufacturer has gained CE , Rosh, FCC
authentication etc.
Q:How long is the warranty period of the product?
A:The regular warranty period is 1 year. If you need a longer
warranty, please contact our sales engineer.
Q:What is your package box?
A:Stand are packaged using Honeycomb boxes, wood pallets or flight
case,depending on what is required.
