YODA 65inch 4K Seamless Interactive Smart Board 1.8mm 3840*2160P
Details of product:
1. Thin body, save space,No radiation, good for health.
2. Professional and humanized inner structure, wiring neatly.
3. Low voltage applications, low drive voltage, solid use safety
and reliability improvement.
4. Many specifications and models, size series, variety, convenient
and flexible use, maintenance, update, upgrade easy, long service
life.
5. Fast response time, fast and smooth use.
6. Appearance is classic type, Stents shapes, Chassis or Other
customized.
7. UHD 4K High resolution, display content clearly visible.
8. Aluminum profile frame, a cold-rolled plate.
| Display Information | | Screen Size | 55inch | 65inch | 75inch | 86inch | | Panel Type | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | | Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 | | Resolution | 3840*2160P | 3840*2160P | 3840*2160P | 3840*2160P | | Viewing Angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | | Brightness | 320cd/m2 | 350cd/m2 | 350cd/m2 | 350cd/m2 | | Active Area | 1209.6x 680.4mm | 1428.48x803.52mm | 1649.664x927.936mm | 1913x1084mm | | Contrast Ratio | 4000:1 | 4000:1 | 1200:1 | 1200:1 | | Response Time | 8ms | 8ms | 8ms | 8ms | | Display Color | 8 bit 1.67M | 8 bit 1.67M | 10 bit 1.07B | 10 bit 1.07B | | Field Frequency | 60Hz | 60Hz | 60Hz | 60Hz | | Service Lifetime | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | | Touch System | | Sensing Type | Infrared System (Multi 10 point touch) | | Response Time | 6ms | | Connection | Full-speed USB (Driver free) | | Surface Protection | Tempered Glass with 4mm thickness Standard | | Graphic card | Intel HD Graphics, Supports 1080P, H264, 3D play | | Bluetooth | Bluetooth4.0 | | Speaker | 15W x2 | | Network | WIFI/ RJ45 | | Port | USB2.0*2/ USB3.0*2/ HDMI out*1/ VGA out*1/ RJ45 Lan port*1/ Speaker
out*1/ Mic in*1 | | Built-in Dual System Android and Windows | | Operating System | Android 6.0 | | CPU | Quad Core Cortex A7 1.8 GHZ | | RAM | DDR3 2G | | ROM | 32G | | SD card slot | Support MAX 128G | | Port | RJ45*1, VGA OUT*1, VGA IN*1, VGA AUDIO IN*1, Ypbpr IN*1, AV IN*2,
AV OUT*1, Earphone*1, TV*1, Spdif OUT*1, HDMI IN*2, USB2.0*2, SD
card slot*1, Touch USB*2, MIC*1 | | Languages | English, French, Germany, Arabic, Italian, Japanese,Korean,
Russian, Spanish, etc | | Power | | Power Supply | 96~264V AC, 50/60Hz | | Power Consumption | 220W~500W | | Operating Temperature | 0℃~50℃ | | Storage Temperature | -10℃~70℃ | | Supplied Accessories | AC Power Cable, 4-in-1 Remote Control, Touch Pens*2, whiteboard
software | | Ambient Conditions | | Dimension (L*W*H) | 1290.5*817.6*99.3mm | 1516.3*947.1*96mm | 1737.7*1072.6*103mm | 1991.1x1212.6x125.6mm | | Package L*W*H | 1427*963*232mm | 1646*1062*230mm | 1860*1230*260mm | 2136*1370x280mm | | Net weight | 40KG | 50KG | 68KG | 76KG |
|
Real-picture
Product's details
Application
FAQ
Q:How long is the warranty time for your products?
A: 1-year warranty, lifetime maintenance.
Can I customize the product I ordered?
A: Absolutely yes, customization offer from customers are most
welcome in our company.
Q:Do you give any discount?
A:We are Manufacturer, so we are able to give you the best price
and best service at the same time.
Q:What is the minimum order quantity?
A:The MOQ is 1. Welcome to order samples. Quality is our
confidence.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept
T/T,L/C,Western
Union,Paypal.
Q:What's the shipment terms and delivery time of your company?
A:The goods can be shipped by courier,by air or by sea. Depend on
quantity and
customer's requirement.
