Details of product:
1. Professional and humanized inner structure, wiring neatly.
2. Appearance is classic type, Stents shapes, Chassis or Other
customized.
3. Various version, different configurations, different prices.
4. The 10-point touch function can be used by many people at the
same time.
5. Support USB playback, support hot plug, content update
convenient and fast.
6. Low voltage applications, low drive voltage, solid use safety
and reliability improvement.
7. The appearance design is very thin, the touch use effect is
good.
8. Fast response time, fast and smooth use.
| Display Information | | Screen Size | 55inch | 65inch | 75inch | 86inch | | Panel Type | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | | Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 | | Resolution | 3840*2160P | 3840*2160P | 3840*2160P | 3840*2160P | | Viewing Angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | | Brightness | 320cd/m2 | 350cd/m2 | 350cd/m2 | 350cd/m2 | | Active Area | 1209.6x 680.4mm | 1428.48x803.52mm | 1649.664x927.936mm | 1913x1084mm | | Contrast Ratio | 4000:1 | 4000:1 | 1200:1 | 1200:1 | | Response Time | 8ms | 8ms | 8ms | 8ms | | Display Color | 8 bit 1.67M | 8 bit 1.67M | 10 bit 1.07B | 10 bit 1.07B | | Field Frequency | 60Hz | 60Hz | 60Hz | 60Hz | | Service Lifetime | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | | Touch System | | Sensing Type | Infrared System (Multi 10 point touch) | | Response Time | 6ms | | Connection | Full-speed USB (Driver free) | | Surface Protection | Tempered Glass with 4mm thickness Standard | | Graphic card | Intel HD Graphics, Supports 1080P, H264, 3D play | | Bluetooth | Bluetooth4.0 | | Speaker | 15W x2 | | Network | WIFI/ RJ45 | | Port | USB2.0*2/ USB3.0*2/ HDMI out*1/ VGA out*1/ RJ45 Lan port*1/ Speaker
out*1/ Mic in*1 | | Built-in Dual System Android and Windows | | Operating System | Android 6.0 | | CPU | Quad Core Cortex A7 1.8 GHZ | | RAM | DDR3 2G | | ROM | 32G | | SD card slot | Support MAX 128G | | Port | RJ45*1, VGA OUT*1, VGA IN*1, VGA AUDIO IN*1, Ypbpr IN*1, AV IN*2,
AV OUT*1, Earphone*1, TV*1, Spdif OUT*1, HDMI IN*2, USB2.0*2, SD
card slot*1, Touch USB*2, MIC*1 | | Languages | English, French, Germany, Arabic, Italian, Japanese,Korean,
Russian, Spanish, etc | | Power | | Power Supply | 96~264V AC, 50/60Hz | | Power Consumption | 220W~500W | | Operating Temperature | 0℃~50℃ | | Storage Temperature | -10℃~70℃ | | Supplied Accessories | AC Power Cable, 4-in-1 Remote Control, Touch Pens*2, whiteboard
software | | Ambient Conditions | | Dimension (L*W*H) | 1290.5*817.6*99.3mm | 1516.3*947.1*96mm | 1737.7*1072.6*103mm | 1991.1x1212.6x125.6mm | | Package L*W*H | 1427*963*232mm | 1646*1062*230mm | 1860*1230*260mm | 2136*1370x280mm | | Net weight | 40KG | 50KG | 68KG | 76KG |
|
Product's details
Application
FAQ
Q:What is your package box?
A:Stand are packaged using Honeycomb boxes, wood pallets or flight
case,
depending on what is required.
Q:What's your guarantee for the products?
A:All our products have one-year guarantee from the shipping date.
And it is ok to upgrade to two or three years guarantee with
additional cost.
Q:Do you give any discount?
A:We are Manufacturer, so we are able to give you the best price
and best service at the same time.
Q: If you are not online,how can i get contact with you?
A:if i am not online,please kindly check the following contact
information,you can send me
email,you can call me or skype me,i will reply you ASAP.
Q:What is your standard lead time for sample and bulk order?
A:Sample within 7-15 days,bulk order is depends on quantity.
Q:Are you a Manufacturer or Trading Company?
A:We are a professional Advertising Display and LCD Touch Screen
manufacturer since 2016 with consistent quality control and very
positive & approving customer feedback.
